Description:
Automatic Fast Spiral Door made of insulated aluminum sheet with PU foam are sturdy and reliably constructed, andAutomatic Sectional Spiral Doorsare ideally suited for commercial and industrial applications. The 225mm PU foam insulation material has an excellent R value.
Specifications:
|
Curtain： |
RAL codes aluminum sheet 0.7mm, PU foam 43mm (50mm) ,width 225mm, or hollow aluminum panel, transparent panel etc. |
|
Drive system: |
Drive dedicated motor power: 0.75-3KW; voltage 220V/380V, |
|
Control system: |
The IP56 control box with LED screen is compatible with commonly used protection devices; the whole uses PLC digital programming to realize the safe passage of personnel vehicles and articles,parking manual lever for easy to open or close |
|
Operating & closing speed |
Upward 0.5~2.5m/s, down 0.6~1.0m/s, and the inverter can be adjusted the required uplink and downlink speed according to actual requirements. |
|
Anti-wind grade |
DIN EN 12424 |
|
Max.size: |
Width 15m x height 15m |
|
Switch mode: |
Manual buttons Triplex or touchless motions sensor |
|
Motor warranty 1years |
|
Hydrodynamic mechanism:
The door curtain is divided into body assembly structure: aluminum alloy door plate with heat insulation of broken bridge, multi-layer sealing tape, muffler bearing hinge, polyurethane guide wheel and other parts:
1. The standard thickness of the thermal insulation door plate is 40mm, and the surface is treated with anodic oxidation and organic coloring. The wind resistance can reach level 12.According to the international standard ,the optional colors are silver gray, pearl white, champagne, gray, blue, etc.
2. Seal the door panels with soft connecting strips, and the folding life of the soft connecting parts is over one million times.
3. The design of hinge bearing mode makes the joint of the door curtain not bear force, and the door plate is not in contact with each other, so that it can keep flat after a long time.
The door body slides in the aluminum alloy track through the polyurethane guide wheel and runs at high speed.
Our Services:
1. Provide professional technical support.
2. Send product catalog and instruction manual.
3. If you have any questions, please PLS contact us online or send us an e-mail, we guarantee that we will reply to you as soon as possible!
4. According to the size of the customer's site, we can provide CAD, solid-work, UG drawing communication and confirmation before ordering.
